ANSYS Workbench Integration Overview > ANSYS EM to ANSYS Geometry Transfer
Geometry Transfer through ANSYS DesignModeler (DM)
It is possible to edit geometry in ANSYS DesignModeler (DM) before consuming in Mechanical
• Useful when geometry needs preprocessing for ANSYS simulation
• Can take advantage of geometry commands available in DM
For example, consider an HFSS model linked to DM through the Workbench.
![[spacer]](1p.gif){kind=small}
In this case, the figure below shows how a chamfer operation on geometries is imported.
It is possible to edit geometry in ANSYS DesignModeler (DM) before consuming in Mechanical
• Useful when geometry needs preprocessing for ANSYS simulation
• Can take advantage of geometry commands available in DM
